OSSC - Open Source Scan Converter (Version 1.6)

OSSC

  • £ 139.99 GBP


The OSSC allows you to use your retro games consoles on modern Television's by converting, Scart, Component & VGA to HDMI/DVI. Best of all it has no input lag.

Feature:

- The OSSC uses FGPA technology allowing you to use your original consoles on modern HDTV's and provides a fantastic picture quality with no input lag.

- Converts Scart, Component & VGA to HDMI/DVI.

- Eliminates blurry graphics, interlaced jams, and higher input lags, and painstaking upgrades.

- OSSC concept adopted without delay line multiplier will take you into the digital age.



FAQ

Supporting Model

Retro home consoles

Atari 2600

Atari 5200

Atari Jaguar

Microsoft Xbox

Microsoft Xbox 360

NEC PC Engine

Nintendo 64

Nintendo NES / Famicom

Nintendo Gamecube

Nintendo Super NES / Super Famicom

Nintendo Wii

Sega Dreamcast

Sega Genesis / Mega Drive

Sega Master System

Sega Saturn

SNK Neo Geo

Sony PlayStation

Sony PlayStation 2

Sony PlayStation Portable

Computers

Atari 8-bit family

Commodore Amiga

Commodore 64

MGT Sam Coupé

MSX

Sinclair ZX Spectrum

Arcade Boards

Capcom CPS-II Data East Caveman Ninja Hardware Irem M92 Nintendo Playchoice 10 Namco Gaplus Sega Model 2 Seibu SPI SNK Hal 21 SNK Neo Geo MVS Sony ZN-1 Taito F2 Taito FX-1B Taito F3 Toaplan V1 Toaplan V2

Specification:

Inputs

1 X SCART – Supports RGBs (clean csync, cvideo sync, luma sync), RGsB, Ypbpr

1 X Component video – Supports Ypbpr and RGsB signals

1 X D-SUB15 (VGA) – Supports RGBHV, RGBs, RGsB, Ypbpr

2 x 3.5mm analogue audio – Supports all analogue audio. Input 1 can be toggled between output (from AV1/SCART) or input Composite video and S-Video are NOT supported and require an adapter/transcoder

Outputs

1 X HDMI or DVI-D (with adapter) (digital only, including audio). Full-range 24-bit RGB output through DVI/HDMI

1 X Analogue audio 3.5mm (input/output toggle)

Supported input resolutions

240p/288p/480i/576i 15khz

25Khz medium-res modes

480p/576p/720p/1080i 31khz

Supported output resolutions

240p/288p -> 480p/576p or 720p line triple (compatible displays only)

240p/288p -> 1280×960, 1280×1152, 1080p, 1600×1200 line quadruple/quintuple (compatible displays only)

25Khz medium-res modes -> 480p

480i/576i -> 480p/576p or pass-through

480p -> pass-through or 960p line-double (compatible displays only)

all other 31khz resolutions passed through

Other features

Back lit LCD

SD Card socket for firmware updates

JTAG connector

IR receiver

OSSC Wiki

What is Included

USB Type C to A Cable + Adapter + Earphone Headset + User Manual + Warranty Card.
